Products specifications

Categories RF/IF and RFID
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type TxRx Only
RF Family/Standard General ISM
Modulation 2FSK, 4FSK, ASK, GFSK, MSK, OOK
Frequency 300MHz to 348MHz, 387MHz to 464MHz, 779MHz to 928MHz
Data Rate (Max) 600kbps
Power - Output 12dBm
Sensitivity -116dBm
Serial Interfaces SPI
Supply Voltage - Operating 1.8 V to 3.6 V
Current - Receiving 14.3mA to 17.1mA
Current - Transmitting 12.3mA to 34.2mA
Temperature Range - Operating -40°C to 85°C
Dimension 20-VFQFN Exposed Pad
Win Source Part Number 012746-CC1101RGPR
Family Name CC1101
ECCN 5A991.b
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian CC1101RGPR CAD Model

Description

Product Overview

The CC1101RGPR is a highly integrated, multi-channel RF transceiver designed for low-power wireless applications in the sub-1 GHz band. Ideal for use in industrial, scientific, and medical (ISM) bands, it provides robust performance and extended range, making it a versatile solution for wireless connectivity.

Features and Benefits

  • Low power consumption allows for extended battery life in portable devices.
  • Advanced modulation techniques ensure reliable data transmission.
  • Wide frequency range supports multiple global ISM bands.

Applications

  • Smart metering
  • Wireless sensor networks
  • Remote controls
  • Industrial automation systems

Additional Details

The CC1101RGPR incorporates features like asynchronous and synchronous serial operation, 128-byte data FIFO, and forward error correction (FEC) support for increased reliability. With its compact QFN package, it is suitable for space-constrained designs.
