ADC0838CCWMX/NOPB Texas Instruments ADC0838CCWMX/NOPB Real Image ADC0838CCWMX/NOPB label picture 2 ADC0838CCWMX/NOPB real image
Same model may have multiple batches, images only for reference.
ADC0838CCWMX/NOPB Texas Instruments ADC0838CCWMX/NOPB Real Image ADC0838CCWMX/NOPB label picture 2 ADC0838CCWMX/NOPB real image
ADC0838CCWMX/NOPB Texas Instruments ADC0838CCWMX/NOPB Real Image ADC0838CCWMX/NOPB label picture 2 ADC0838CCWMX/NOPB real image
Same model may have multiple batches, images only for reference.

ADC0838CCWMX/NOPB

Part No ADC0838CCWMX/NOPB
Manufacturer Texas Instruments
Catalog Data Acquisition - Analog to Digital Converters (ADC)
Description IC ADC 8BIT SERIAL I/O 20-SOIC
Datasheet
ADC0838CCWMX/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Number of Bits 8
Number of Inputs 4, 8
Input Type Differential, Pseudo-Differential, Single Ended
Data Interface SPI
Configuration MUX-ADC
Number of A/D Converters 1
Reference Type External
Analog Supply Voltage 4.5 V to 6.3 V
Digital Supply Voltage 4.5 V to 6.3 V
Temperature Range - Operating 0°C to 70°C
Case / Package 20-SOIC
Win Source Part Number 117656-ADC0838CCWMX/NOPB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name ADC0838
Introduction Date August 01, 1999
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian ADC0838CCWMX/NOPB CAD Model

Description

ADC0838CCWMX/NOPB - Enhanced 8-Bit A/D Converter

The ADC0838CCWMX/NOPB is engineered to deliver superior performance in analog-to-digital conversion tasks. It is equipped with multiple channels and an easy-to-use interface, rendering it an excellent choice for modern electronic projects.

  • 8-Bit Resolution
  • 8 Analog Input Channels
  • Maximum Sampling Rate: 40 kSPS
  • Wide Power Supply Range: 2.7V to 5.5V
  • SPI-Compatible Serial Interface
  • Compact Package for Space-Saving Designs

Applications

  • Communication Devices
  • Environmental Monitoring
  • Digital Signal Processing
  • Home Automation

This component not only guarantees accurate analog input data conversion but also complements low-power applications, strengthening your project's performance.
