S87R5A2B1D1-240 TE Connectivity – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

S87R5A2B1D1-240

Part No S87R5A2B1D1-240
Manufacturer TE Connectivity
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE SPDT 20A 240V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Obsolete
Mounting Type Chassis Mount
Coil Voltage 240VAC
Contact Form SPDT (1 Form C)
Contact Rating (Current) 20 A
Switching Voltage 277VAC - Max
Load - Max Switching 5540VA
Coil Current 16.5 mA
Coil Type Non Latching
Termination Style Quick Connect - 0.250" (6.3mm)
Coil Insulation Class B
Must Operate Voltage 204 VAC
Temperature Range - Operating -10°C ~ 65°C
Contact Material Silver Cadmium Oxide (AgCdO)
Approval Agency CSA, UR
Relay Type General Purpose
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1550107-S87R5A2B1D1-240
Ultra Librarian 3D Model Ultra Librarian S87R5A2B1D1-240 CAD Model
