Same model may have multiple batches, images only for reference.
RS512-4-02 TE Connectivity – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

RS512-4-02

Part No RS512-4-02
Manufacturer TE Connectivity
Catalog Common Mode Chokes
Description CMC 3UH 4A 2LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Obsolete
Filter Type Signal Line
Number of Lines 2
Inductance @ Frequency 3 µH @ 1 kHz
Current Rating (Max) 4A (Typ)
DC Resistance (DCR) (Max) 10mOhm (Typ)
Voltage Rating - AC 250V
Temperature Range - Operating -40°C ~ 125°C
Approval Agency UR, VDE
Mounting Type Through Hole
Size / Dimension 0.697" L x 0.673" W (17.70mm x 17.10mm)
Height (Max) 0.492" (12.50mm)
Case / Package Horizontal, 4 PC Pin
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1530610-RS512-4-02
Ultra Librarian 3D Model Ultra Librarian RS512-4-02 CAD Model
