RB6132-16-0M8

Part No RB6132-16-0M8
Manufacturer TE Connectivity
Catalog Common Mode Chokes
Description CMC 800UH 16A 3LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power Line
Number of Lines 3
Inductance @ Frequency 800 µH @ 400 Hz
Current Rating (Max) 16A
DC Resistance (DCR) (Max) 4.6mOhm (Typ)
Voltage Rating - DC 1000V (1kV)
Voltage Rating - AC 600V
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Through Hole
Size / Dimension 2.315" L x 2.276" W (58.80mm x 57.80mm)
Height (Max) 1.890" (48.00mm)
Case / Package Horizontal, 4 PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1530565-RB6132-16-0M8
Ultra Librarian 3D Model Ultra Librarian RB6132-16-0M8 CAD Model
