Same model may have multiple batches, images only for reference.
293545-2 Real Image
Same model may have multiple batches, images only for reference.

293545-2

Part No 293545-2
Manufacturer TE Connectivity
Catalog Terminals
Description CONN INLINE TAP 18 AWG IDC  /  Terminal Inline, Tap Connector IDC 18 AWG Translucent - Blue
Datasheet
293545-2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Terminals - Wire Splice Connectors
Mfr TE Connectivity AMP Connectors
Series CoolSplice
Package Bulk
Product Status Obsolete
Terminal Type Inline, Tap
Number of Wire Entries 4
Termination IDC
Wire Gauge 18 AWG
Insulation Fully Insulated
Color Translucent - Blue
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.69.8000
Other Names -293545-2-SI,-293545-2-CSI,2266-293545-2,2935452,-293545-2-LSI,A101520
Standard Package 15
Win Source Part Number 1031418-293545-2
Ultra Librarian 3D Model Ultra Librarian 293545-2 CAD Model

Description

The TE Connectivity AMP Connectors CoolSplice is a fully insulated wire splice connector that comes in a translucent-blue color.

  • Termination: IDC
  • Terminal Type: Inline/Tap
  • Wire Entries: 4
  • Standard Package: 15 pieces
  • ECCN: EAR99
  • Alternative Parts: RHD2-6, 19216-0010, 293545-1, 19216-0011, 564-BULK, 560 (BOXED), and 2-1601002-2293545-2
  • HTSUS: 8536.69.8000
  • Manufacturer: TE Connectivity AMP Connectors
