2834171-3 TE Connectivity
Same model may have multiple batches, images only for reference.

2834171-3

Part No 2834171-3
Manufacturer TE Connectivity
Catalog Solid State Lighting Connectors
Description ULTRAMINIATURE SLIM CONTACT / 20-24 AWG SSL Contact, Poke-In Wire Solder Surface Mount, Right Angle
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Solid State Lighting Connectors - Solid State Lighting Connector Contacts
Mfr TE Connectivity AMP Connectors
Series -
Package Tape & Reel (TR)
Product Status Active
Style Board to Cable/Wire
Connector Type Contact, Poke-In Wire
Mounting Type Surface Mount, Right Angle
Termination Solder
Pitch -
Wire Gauge 20-24 AWG
Features -
Contact Finish Tin
Contact Material Copper Alloy
Fastening Type -
Housing Color -
Housing Material -
Temperature Range - Operating -40°C ~ 105°C
Voltage Rating 300 V
Current Rating (Amps) -
Mating Cycles -
Base Product Number 2834171
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.90.4000
Win Source Part Number 1363924-2834171-3
Ultra Librarian 3D Model Ultra Librarian 2834171-3 CAD Model

Description

The Solid State Lighting Connector Contacts are designed for use in solid state lighting applications. Manufactured by TE Connectivity AMP Connectors, these contacts are part of the Solid State Lighting Connectors series.

  • Series: Solid State Lighting Connectors
  • Mounting Type: Surface Mount, Right Angle
  • Contact Finish: Tin
  • Wire Gauge: 20-24 AWG
  • Voltage Rating: 300V
  • Product Status: Active
