The TE Connectivity 1-1414761-0 is a 12V SPDT (Single Pole Double Throw) automotive relay with a maximum switching current of 30A (NO) / 25A (NC). It is a through-hole relay with PC pin terminals. It has a coil resistance of 254Ω and a coil current of 47.2mA. The relay has an operating temperature range of -40°C to 105°C.

Features and Benefits

• High switching current capacity (30A NO / 25A NC)
• Compact size (12.9mm x 12mm x 9.9mm)
• Through-hole mounting with PC pin terminals
• Wide operating temperature range (-40°C to 105°C)
• RoHS compliant

Applications

The TE Connectivity 1-1414761-0 relay is ideal for a wide range of automotive applications, including:

• Headlights
• Fog lights
• Tail lights
• Brake lights
• Fuel pumps
• Electric fans
• Air conditioning compressors
• Starter motors
• Power windows
• Door locks
• Seat heaters

How to Use

The TE Connectivity 1-1414761-0 relay is a simple two-coil relay. To use it, you will need to connect a power supply to the coil terminals. When the coil is energized, the relay will switch to the NO (Normally Open) state. When the coil is de-energized, the relay will switch to the NC (Normally Closed) state.

Safety Considerations

When using the TE Connectivity 1-1414761-0 relay, it is important to follow all safety precautions. This includes:

• Always disconnect the power supply before working on the relay.
• Use proper insulation to prevent electrical shock.
• Do not overload the relay.
• Do not use the relay in hazardous environments.

Conclusion

The TE Connectivity 1-1414761-0 is a reliable and versatile automotive relay. It is ideal for a wide range of applications, including headlights, fog lights, tail lights, brake lights, fuel pumps, electric fans, air conditioning compressors, starter motors, power windows, door locks, and seat heaters.

Additional Information

Here is some additional information about the TE Connectivity 1-1414761-0 relay:

• Contact material: Silver tin oxide (AgSnO)
• Contact rating: 30A NO / 25A NC
• Switching voltage: 12VDC
• Must operate voltage: 6.9VDC
• Must release voltage: 1.5VDC
• Operate time: 3ms
• Release time: 1.5ms
• Mounting type: Through hole
• Termination style: PC pin
• Number of terminals: 5

How to Order

The TE Connectivity 1-1414761-0 relay can be ordered from a variety of electronic distributors. It is important to note that this relay has a long lead time, so it is important to order it in advance.
