PH150F4828 Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Mounting SMD (SMT)
Case / Package Module
Current - Output 1 5.4 A
Depth 86 mm
Features OCP, OVP
Height 12.7 mm
Isolation Isolated
Isolation Voltage 3 kV
Length 86.106 mm
Max Input Voltage 76 V
Maximum Operating Temperature 85 °C
Max Output Current 5.4 A
Max Power Dissipation 150 W
Min Input Voltage 36 V
Min Operating Temperature -20 °C
Mount Through Hole
Number of Outputs 1
Number of Pins 14
Output Current 5.4 A
Output Power 150 W
Output Voltage 28 V
Packaging Bulk
RoHS Compliant
Voltage - Output 1 28 V
Width 83.058 mm
Win Source Part Number 1031239-PH150F4828
Categories Board Mount Modules
Manufacturer TDK-Lambda Americas Inc.
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian PH150F4828 CAD Model

Description

This electronic component is manufactured by TDK-Lambda Americas Inc. and has a Win Source Part Number of 1031239-PH150F4828.

  • Features: OCP and OVP
  • Length: 86.106 mm
  • Mounting: SMD (SMT)
  • Isolation: Isolated
  • Height: 12.7 mm
  • Pins: 14
  • Isolation Voltage: 3 kV
  • Outputs: One
  • Output Current: 5.4 A
  • Output Voltage: 28 V
  • Output Power: 150 W
  • Width: 83.058 mm
  • Category: Board Mount Modules
  • Case/Package: Module
  • Maximum Operating Temperature: 85 degrees Celsius
  • Depth: 86 mm
  • Mounting Type: Through Hole
  • RoHS Compliant: Yes
  • Minimum Operating Temperature: -20 degrees Celsius
  • Maximum Power Dissipation: 150 W
  • Maximum Output Current: 5.4 A
  • Minimum Input Voltage: 36 V
