Same model may have multiple batches, images only for reference.
MBR30L100CT Sirectifier Global Corp.
Same model may have multiple batches, images only for reference.

MBR30L100CT

Part No MBR30L100CT
Manufacturer Taiwan Semiconductor
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 100V TO220
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr Taiwan Semiconductor
Package Tube
Product Status Discontinued
Diode Configuration 1 Pair Common Cathode
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 100 V
Current - Average Rectified (Io) (per Diode) 30A
Voltage - Forward (Vf) (Max) @ If 770 mV @ 15 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 500 µA @ 100 V
Operating Temperature - Junction -55°C ~ 150°C
Mounting Type Through Hole
Package / Case TO-220-3
Supplier Device Package TO-220AB
Base Product Number MBR30
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 633433-MBR30L100CT
Ultra Librarian 3D Model Ultra Librarian MBR30L100CT CAD Model

Description

The 633433-MBR30L100CT is a fast recovery Schottky diode array designed for rectification applications.

  • Maximum Reverse Voltage: 100V
  • Average Rectified Current: 30A
  • Forward Voltage Drop: 770mV @ 15A
  • Current Leakage: 500μA
  • Mounting Type: through hole
  • Package: TO-220-3
  • Standard Package: 50 pieces
  • Manufacturer: Taiwan Semiconductor
  • Component Status: discontinued
