BYG21M Real Image BYG21M real image17723
Same model may have multiple batches, images only for reference.
BYG21M Real Image BYG21M real image17723
BYG21M Real Image BYG21M real image17723
Same model may have multiple batches, images only for reference.

BYG21M

Part No BYG21M
Manufacturer Taiwan Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE AVALANCHE 1.5A DO214AC / Diode 1000 V 1.5A Surface Mount DO-214AC (SMA)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr Taiwan Semiconductor
Package Tape & Reel
Product Status Active
Technology Avalanche
Voltage - DC Reverse (Vr) (Max) 1000 V
Current - Average Rectified (Io) 1.5A
Voltage - Forward (Vf) (Max) @ If 1.6 V @ 1.5 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 120 ns
Current - Reverse Leakage @ Vr 1 µA @ 1000 V
Capacitance @ Vr, F 13pF @ 4V, 1MHz
Mounting Type Surface Mount
Package / Case DO-214AC, SMA
Supplier Device Package DO-214AC (SMA)
Operating Temperature - Junction -55°C ~ 150°C
Base Product Number BYG21
Standard Package 7,500 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 573947-BYG21M
Ultra Librarian 3D Model Ultra Librarian BYG21M CAD Model

Description

The BYG21M is a single diode rectifier that is designed for fast recovery applications.

  • Maximum DC Reverse Voltage: 1000V
  • Average Rectified Current: 1.5A
  • Forward Voltage: 1.6V @ 1.5A
  • Reverse Leakage Current: 1μA @ 1000V
  • Capacitance: 13pF @ 4V, 1MHz
  • Operating Temperature: -55°C to 150°C
  • Package: DO-214AC, SMA (Surface Mount)
  • Packaging: Tape and Reel (7,500 pieces)
  • Product Status: Active
  • Manufacturer: Unknown
