ON Semiconductor NCP301LSN20T1G Voltage Detector

The ON Semiconductor NCP301LSN20T1G is a high-performance voltage detector designed for the precise monitoring of power supply voltages. This compact and reliable component is essential for applications that require voltage supervision to protect sensitive electronic circuits from improper operation at low voltage conditions.

Key Features

• Threshold Voltage: The device has a preset threshold voltage of 2.0V, which is ideal for monitoring 2V power supplies.
• High Accuracy: It offers a high accuracy of ±1.5%, ensuring reliable voltage detection and system protection.
• Low Current Consumption: With a quiescent current of typically 3 µA, the NCP301LSN20T1G is suitable for battery-powered applications where power efficiency is crucial.
• Reset Time Delay: The built-in programmable delay time improves system reliability by preventing false triggering due to transient voltages.
• Output Type: It provides an active-low, open-drain reset output, which can be easily interfaced with a variety of microcontrollers or other digital systems.
• Temperature Range: The device operates over a wide temperature range of -40°C to +125°C, making it suitable for industrial and automotive environments.
• Package: Housed in a space-saving 5-pin TSOP package, the NCP301LSN20T1G is designed for surface mount technology, allowing for a compact PCB design.

Applications

The NCP301LSN20T1G is versatile and can be used in a variety of applications, including:

• Portable/Battery-Powered Equipment
• Microprocessor/Microcontroller Systems
• Industrial Equipment
• Automotive Systems
• Notebook Computers
• Communication Devices

ON Semiconductor's commitment to quality ensures that the NCP301LSN20T1G voltage detector meets the stringent requirements of electronic systems, providing a reliable solution for voltage monitoring and system protection.
