The Z1SMA180 is a surface mount transient voltage suppressor (TVS) diode manufactured by TAITRON Components Incorporated. It is engineered to safeguard sensitive electronic devices from voltage surges that can result from lightning strikes, electrostatic discharge (ESD), and inductive switching. Its primary function is to quickly clamp the voltage to a safe level, thereby preventing damage to downstream components.

Applications

• Protection of sensitive electronic equipment
• Data line protection
• Power line protection
• Telecommunications equipment
• Industrial control systems

Features

• Surface mount SMA package for automated assembly
• Fast response time, typically in picoseconds
• High peak pulse power dissipation capability
• Low clamping voltage to minimize stress on protected circuits
• Glass passivated junction for high reliability
• RoHS compliant

Benefits

• Enhanced system reliability by preventing damage from voltage transients
• Reduced equipment downtime and maintenance costs
• Simplified board layout and assembly
• Increased product lifespan
• Compliance with environmental regulations

Detailed Specs

The Z1SMA180 features a standoff voltage of 18V and a breakdown voltage range of 20V to 22.1V. It's designed to handle a peak pulse power of 400W at a 10/1000μs waveform. The device exhibits a low clamping voltage, ensuring effective suppression of voltage spikes. Its surface mount SMA package allows for efficient heat dissipation. The Z1SMA180 operates within a broad temperature range and is constructed using a glass passivated junction, enhancing its robustness. This TVS diode meets industry safety standards, delivering a dependable solution for surge protection.
