The Susumu RR1220P-113-B-T5 is a precision thin film chip resistor designed for applications requiring high stability and accuracy. As a part of Susumu's RR series, this resistor is suitable for circuits demanding tight tolerances and reliable performance under various environmental conditions. This model features a resistance value of 11 kOhms (113 = 11 x 10^2 ohms = 11000 ohms) with a tolerance of ±0.1% (indicated by 'B'). The 'T5' suffix signifies tape and reel packaging for automated assembly.

Applications

• Precision Instrumentation: Used in devices that require highly accurate and stable resistance values, such as calibration equipment and precision amplifiers.
• Medical Devices: Employed in medical monitoring and diagnostic equipment where reliability and precision are paramount.
• Test and Measurement Equipment: Found in instruments that demand precise resistance for accurate readings and measurements.
• Industrial Automation: Integrated into control systems and sensor circuits requiring stable and precise resistance values.
• Aerospace Applications: Used in aerospace electronics systems where robust and reliable components are essential.

Features

• Thin Film Technology: Offers excellent stability, low noise, and high precision, ensuring reliable performance.
• Precise Resistance Value: Provides a stable resistance value of 11 kOhms with a tight tolerance of ±0.1%.
• Small Size: 1220 chip size allows for integration into compact and densely populated circuit boards.
• High Reliability: Designed to withstand a wide range of environmental conditions, ensuring long-term performance.
• Low Temperature Coefficient of Resistance (TCR): Ensures stable performance across a wide temperature range, minimizing resistance variations.

Benefits

• Enhanced Circuit Accuracy: The tight tolerance ensures precise and reliable circuit operation, improving overall performance.
• Improved Stability: The thin film construction provides stable resistance values over time and temperature, ensuring consistent operation.
• Reduced Noise: Low noise characteristics improve signal integrity in sensitive applications, resulting in more accurate measurements.
• Compact Design: Small size allows for efficient integration into densely populated circuit boards, saving valuable space.
• Long-Term Reliability: Ensures consistent performance over the lifespan of the equipment, reducing maintenance and replacement costs.

Additional Details

The RR1220P-113-B-T5 resistor is manufactured using advanced thin film techniques, where a thin layer of resistive material is deposited onto a ceramic substrate. This process provides exceptional control over the resistance value and ensures long-term stability. The 1220 chip size defines the physical dimensions of the resistor. The component meets RoHS compliance, guaranteeing that it does not contain hazardous substances. The 'T5' designation indicates that the resistor is supplied on tape and reel for automated pick-and-place assembly, streamlining the manufacturing process. The typical power rating is around 0.1W. The operating temperature range typically extends from -55°C to +155°C.
