The SDWL1608C39NJSTF is a wire-wound chip inductor manufactured by Sunlord, designed for applications that demand precise inductance for filtering, impedance matching, and tuning in high-frequency circuits.

Applications

• Mobile Communication: Used in the RF front-end for impedance matching and filtering.
• Wireless LAN: Applied in WLAN modules for optimal signal transmission and reception.
• Bluetooth Devices: Used in Bluetooth circuits for impedance matching and filtering.
• RF Transceivers: Employed in RF transceiver circuits for impedance matching and tuning.
• IoT Devices: Integrated into IoT devices to enhance wireless communication performance.

Features

• Compact Size: 1.6mm x 0.8mm x 0.8mm dimensions allow for high-density PCB designs.
• High Q Factor: Provides superior performance in high-frequency applications.
• Tight Inductance Tolerance: Ensures consistent performance across different units.
• Wire-Wound Construction: Offers better electrical characteristics than multilayer inductors.
• Surface Mount Technology (SMT): Facilitates automated assembly and reduces manufacturing costs.

Benefits

• Miniaturization: Enables the design of smaller and more compact electronic devices.
• Improved Performance: The high Q factor and tight inductance tolerance enhance circuit performance.
• Reliable Operation: Robust construction ensures stable performance in various operating conditions.
• Ease of Assembly: SMT compatibility simplifies the PCB assembly process.
• Cost-Effective: Offers a balance of performance and cost-effectiveness for numerous applications.

Specifications

The SDWL1608C39NJSTF has an inductance value of 39nH. Key specifications also include Self-Resonant Frequency (SRF), DC Resistance (DCR), and Rated Current. Consult the official datasheet from Sunlord for precise values regarding these specifications, as they are essential for accurate circuit design and implementation. This component is suitable for standard SMT assembly processes.
