The STPS2L30A is a robust Schottky rectifier designed by STMicroelectronics, a leader in semiconductor solutions. This component is engineered for high-efficiency power supply applications and is particularly suitable for switch-mode power supplies and high-frequency DC to DC converters.

Key Features

• Low Forward Voltage Drop: The STPS2L30A has a low forward voltage drop, which helps in reducing power loss and improving efficiency during operation.
• High Surge Current Capability: This rectifier is capable of handling high surge currents, making it reliable in applications where surge protection is critical.
• High Junction Temperature: With a maximum junction temperature of 150°C, the STPS2L30A is suitable for high-temperature environments, ensuring stability and longevity.

Electrical Characteristics

• Average forward current: 2 A
• Repetitive peak reverse voltage: 30 V
• Non-repetitive peak forward surge current: 50 A
• Forward voltage drop: 0.385 V at 2 A
• Junction to ambient thermal resistance: 50 °C/W

Applications

The STPS2L30A is ideal for use in various applications, including:

• Power management systems
• Automotive applications
• DC power equipment
• Battery charging circuits
• Voltage regulators
• Free-wheeling diodes in converters

Package Information

The STPS2L30A is available in a DO-15 package, which is designed for through-hole mounting. This package is known for its ease of installation and strong mechanical endurance, making it a practical choice for various electronic assemblies.

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The STPS2L30A is manufactured with the stringent quality control processes for which ST is known, ensuring reliable performance and a long operational lifespan.
