The STPS1H100AF from STMicroelectronics is a high-performance Schottky rectifier designed to meet the stringent requirements of electronic applications requiring efficient power management. This rectifier is particularly well-suited for switch-mode power supplies, converters, free-wheeling diodes, and reverse battery protection applications.

Key Features

• High Junction Temperature: Capable of operating at high temperatures, this device features a maximum junction temperature of 150°C, ensuring reliability under thermal stress.
• Low Forward Voltage Drop: With a low forward voltage drop, the STPS1H100AF minimizes power loss, making it highly efficient for power conversion.
• High Surge Current Capability: Engineered to handle high surge currents without failure, which is critical for applications subjected to sudden surges.
• Avalanche Rated: This diode is capable of withstanding avalanche conditions, ensuring robust performance and protection for sensitive circuits.

Applications

The STPS1H100AF is versatile and can be used in a variety of applications, including:

• Power Supply Units (PSUs)
• LED Lighting Systems
• Automotive Applications
• Solar Inverters
• Battery Charging Systems
• Telecommunication Equipment

Package and Quality

The STPS1H100AF comes in a robust and compact PowerFLAT™ 5x6 package, which not only saves space but also offers excellent thermal performance. It is compliant with RoHS and Halogen-Free standards, ensuring environmental friendliness and suitability for use in green applications.

Technical Specifications

Parameter Value Repetitive Peak Reverse Voltage (V<sub>RRM) 100 V Average Forward Current (I<sub>F(AV)) 1 A Non-Repetitive Peak Forward Surge Current (I<sub>FSM) 80 A Operating Junction Temperature Range (T<sub>j) -40°C to 150°C Package PowerFLAT™ 5x6

For engineers and designers looking for a reliable and efficient Schottky rectifier, the STPS1H100AF from STMicroelectronics offers a perfect balance of performance and robustness to meet the needs of advanced electronic systems.
