STP12IE95F4 - STMicroelectronics

The STP12IE95F4 is a high-performance power MOSFET designed and manufactured by STMicroelectronics, a global semiconductor leader. This product is part of their STPOWER family, which is renowned for its efficiency and reliability in power management applications. The STP12IE95F4 is specifically engineered to address the demanding needs of a wide range of electronic circuits and systems, offering an optimal blend of fast switching performance, low on-resistance, and high thermal stability.

With a maximum continuous drain current of 12A, the STP12IE95F4 can handle significant power without compromising performance. Its low on-resistance of only 95 mOhm minimizes conduction losses, which is particularly beneficial in high-efficiency power supply designs. The device operates at an enhanced voltage range, with a drain-source voltage (Vds) of up to 600V, making it suitable for high-voltage applications.

The STP12IE95F4 features a rugged design with a fast intrinsic diode, which provides protection against harsh operating conditions and ensures a long operational life. The MOSFET's fast switching capabilities enhance the overall efficiency of power conversion systems and contribute to the reduction of electromagnetic interference (EMI), which is critical in sensitive electronic equipment.

This power MOSFET is housed in a TO-220 package, which is widely used in the industry due to its robustness and excellent thermal performance. The package is designed to be easily mounted onto a heatsink, further enhancing the thermal management of the device. This makes the STP12IE95F4 an ideal choice for a variety of applications including switch-mode power supplies (SMPS), lighting ballasts, motor control circuits, and high-performance computing systems.

STMicroelectronics provides comprehensive technical support for the STP12IE95F4, including datasheets, application notes, and simulation models. This ensures that designers can fully leverage the capabilities of this MOSFET in their applications. With its combination of high efficiency, reliability, and versatility, the STP12IE95F4 is a valuable component for any power management solution.
