STMPS2171TTR Power Switch IC by STMicroelectronics

The STMPS2171TTR from STMicroelectronics is a high-quality, single-channel power switch IC designed for USB and other hot-swap applications. This compact and efficient integrated circuit is housed in a small, surface-mount package, making it an excellent choice for space-constrained designs.

Key Features:

• Current Limiting: The STMPS2171TTR provides precise current limiting to protect the host device from over-current conditions. This feature ensures safe operation for both the IC and the connected peripheral devices.
• Thermal Shutdown: With an integrated thermal shutdown mechanism, the device automatically turns off in the event of overheating, thereby preventing thermal damage.
• Controlled Rise Time: The IC offers a controlled output voltage rise time, which reduces inrush current and minimizes the risk of voltage spikes that could potentially harm connected components.
• Under-Voltage Lockout (UVLO): The under-voltage lockout feature ensures that the switch remains off if the input voltage drops below a certain threshold, thereby protecting the circuit.

Applications:

The STMPS2171TTR is versatile and can be used in a variety of applications, including:

• USB power management
• Hot-swap power control
• Portable and battery-powered devices
• Peripheral power control

Technical Specifications:

• Package: SOT23-5
• Operating Voltage Range: 2.7V to 5.5V
• Continuous Current: Up to 0.5A
• Switch On-resistance: Typically 100mΩ

The STMPS2171TTR is a robust and reliable solution for power distribution and management in modern electronic systems. Its integration of multiple protection features, along with its small form factor, make it an ideal choice for designers looking to enhance the safety and efficiency of their power management schemes.

For further information and complete technical specifications, please refer to the official STMicroelectronics datasheet for the STMPS2171TTR power switch IC.
