Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel
Core Processor STM8
Data Bus Width 8-Bit
Speed 16MHz
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
The number of I/O 16
Program Memory Size 8KB
Program Memory Type FLASH
EEPROM Size 640 x 8
Date RAM Size 1K x 8
Supply Voltage 2.95V ~ 5.5V
Data Converters A/D 5x10b
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package 20-UFQFN
Supplier Device Package 20-UFQFPN (3x3)
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1261552-STM8S103F3U3TR
Manufacturer Homepage www.st.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STM8S103F3U3TR CAD Model

Description

The STM8S103F3U3TR is a versatile microcontroller from STMicroelectronics, designed for budget-friendly applications that require robust performance in a compact package. It is part of STMicroelectronics' STM8S series, which are known for their high efficiency and reliability.

Key Features

  • Core: The STM8S103F3U3TR is built around an advanced STM8 core operating at up to 16 MHz frequency, ensuring swift execution of instructions.
  • Memory: It comes equipped with 8 KB Flash program memory, which is more than sufficient for simple to moderately complex applications. Additionally, it has 1 KB RAM and 128 bytes of EEPROM for data storage, which are both very useful for temporary data storage and non-volatile storage of configuration parameters, respectively.
  • I/O Pins: This microcontroller offers 16 GPIO pins, which are highly configurable and include support for 5V tolerant inputs, allowing for flexible interfacing with a variety of peripherals and sensors.
  • Advanced Peripherals: The STM8S103F3U3TR boasts an array of built-in peripherals including a 10-bit ADC, a TIM1 advanced control timer, TIM2 general purpose timer, and an I2C, UART, and SPI interface for communication.
  • Low Power Consumption: It is designed for energy-efficient operation, making it suitable for battery-powered applications. Various power-saving modes enable the device to optimize power consumption according to the application's requirements.
  • Robust Design: The microcontroller operates within a temperature range of -40°C to +85°C and incorporates built-in brown-out reset, ensuring stable operation under varying conditions.
  • Packaging: The device comes in a compact TSSOP20 package, which is ideal for space-constrained applications.

Applications

The STM8S103F3U3TR is suitable for a wide range of applications, including industrial control systems, home appliances, automotive electronics, and consumer electronics. Its robust feature set and cost-effectiveness make it an excellent choice for both prototyping and mass production.

Conclusion

With its combination of performance, integrated features, and compact form factor, the STM8S103F3U3TR from STMicroelectronics is a compelling choice for designers looking for a reliable and cost-effective microcontroller for their embedded systems.
