STM6524ALABDL6F - Microprocessor Reset Circuit

The STM6524ALABDL6F is a cutting-edge microprocessor reset circuit developed by STMicroelectronics, a global semiconductor leader known for its innovative and reliable products. This component is specifically designed to monitor the supply voltage of microprocessors (µP) and digital systems to ensure a proper reset function without the need for any external components.

Key Features

• Precision Monitoring: It offers precise monitoring of the 2.63V threshold, which is critical for maintaining system stability and reliability.
• Low Power Consumption: The device is optimized for low power consumption, making it suitable for battery-operated applications.
• Reset Time Delay: It includes a built-in delay time which is guaranteed by design, ensuring systems have adequate time to stabilize during power-up.
• High Threshold Accuracy: With a threshold accuracy of ±1.5% at 25°C, the STM6524ALABDL6F provides dependable performance under varying conditions.
• Operating Temperature Range: This device is designed to operate over a wide temperature range, from -40°C to +85°C, accommodating diverse environmental conditions.
• RoHS Compliant: The reset circuit is RoHS compliant, adhering to environmental standards and regulations.

Applications

The STM6524ALABDL6F is suitable for a broad range of applications, including:

• Computers and Computer Peripherals
• Embedded Systems
• Portable/Battery-Powered Devices
• Networking Equipment
• Industrial Controllers

Package and Availability

This device is available in a compact 5-pin SOT23 package, making it ideal for space-constrained applications. Its small footprint allows for easy integration into various designs without compromising performance.

For engineers and designers looking for a reliable microprocessor reset circuit that ensures system integrity, the STM6524ALABDL6F from STMicroelectronics represents a robust solution that combines performance with practicality.
