Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Reset Timer
Number of Voltages Monitored 1
Output Open Drain or Open Collector
Reset Active Low
Reset Timeout 140 ms Minimum
Voltage - Threshold 2.925V
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 8-TDFN
Win Source Part Number 031327-STM6503SEAADG6F
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian STM6503SEAADG6F CAD Model

Description

The STM6503SEAADG6F is a state-of-the-art supervisory circuit designed and manufactured by STMicroelectronics. This compact and efficient device is engineered to monitor power supplies in digital systems, providing a crucial safeguard against power failures and ensuring the stability and reliability of electronic applications.

Key Features

  • Precision Monitoring: The device is capable of precise voltage monitoring, ensuring that the system operates within safe voltage thresholds.
  • Low Power Consumption: It is optimized for low power consumption, making it an ideal choice for battery-operated and power-sensitive applications.
  • Adjustable Voltage Thresholds: The STM6503SEAADG6F offers adjustable voltage thresholds, allowing for customization according to specific system requirements.
  • Multiple Reset Timeout Periods: Users can select from various reset timeout periods, providing flexibility in system design and response strategies.
  • Manual Reset Input: The inclusion of a manual reset input allows for a system reset without the need to cycle power, which is particularly useful for system maintenance and troubleshooting.
  • High Accuracy: The device features high accuracy in voltage threshold detection, which is crucial for maintaining system integrity and preventing data corruption.

Applications

The STM6503SEAADG6F is suitable for a wide range of applications, including but not limited to:

  • Computers and computer peripherals
  • Embedded systems
  • Industrial control systems
  • Portable and handheld devices
  • Telecommunication systems

Technical Specifications

With its compact SOT23-5 package, the STM6503SEAADG6F is designed to fit into tight spaces without compromising performance. The device operates over a wide temperature range, making it suitable for various environmental conditions. It also features built-in hysteresis to prevent false triggering, enhancing system stability.

For engineers and designers seeking a reliable supervisory solution, the STM6503SEAADG6F from STMicroelectronics offers the perfect blend of precision, flexibility, and efficiency. Its robust feature set ensures that it can meet the demands of the most challenging applications.
