STM32F767IGT6 Microcontroller Overview

The STM32F767IGT6 is a high-performance ARM Cortex-M7 based microcontroller from STMicroelectronics, tailored for industrial applications, advanced user interfaces, and complex system integrations. This state-of-the-art MCU is part of the STM32F7 series, which is renowned for its rich feature set and powerful processing capabilities.

Key Features

• Core: ARM Cortex-M7 processor with double-precision floating-point unit, running at a frequency of up to 216 MHz.
• Memory: Equipped with 1 Mbyte of Flash memory and 512+4 Kbytes of RAM, providing ample space for complex applications.
• Performance: Delivering 462 DMIPS/1082 CoreMark performance, thanks to the ART Accelerator™ at 216 MHz.
• Graphics: Chrom-ART Accelerator™ for enhanced graphic content creation, and hardware JPEG codec for multimedia applications.
• Connectivity: Comprehensive set of communication interfaces, including USB OTG HS and FS, Ethernet, CAN, SPI, I2C, USART, SAI, SDMMC, and more.
• Power Efficiency: Multiple power-saving modes, including a low-power run mode for energy-sensitive applications.
• Analog: Advanced analog peripherals, such as 3x 12-bit ADCs, 2x 12-bit DACs, and internal voltage reference, for precise analog signal management.
• Timers: A rich set of timers, including advanced control timers, general-purpose timers, basic timers, and a SysTick timer.
• Security: Features like a True Random Number Generator (TRNG) and hardware cryptographic acceleration for secure data processing and communication.
• Debugging: Integrated debugging and programming capabilities with ST-LINK/V2 through the SWD connector.
• Package: Available in an LQFP176 package, providing a balance between I/O capabilities and a compact footprint.

Applications

The STM32F767IGT6 is designed to serve a wide range of applications, from real-time control systems to complex multimedia user interfaces. It is particularly well-suited for industrial automation, medical equipment, home automation, and IoT devices, where performance, reliability, and power efficiency are critical.

Development Support

STMicroelectronics provides extensive support for development with the STM32F767IGT6, including software libraries, development boards, and a comprehensive Integrated Development Environment (IDE) with STM32CubeMX for peripheral initialization and HAL libraries for system development.
