STM32F407VGT6 Microcontroller

The STM32F407VGT6 is a high-performance microcontroller unit (MCU) from STMicroelectronics, which is part of their advanced STM32F4 series. This powerful MCU is based on the ARM Cortex-M4 processor with a floating-point unit (FPU), delivering superior computational performance suitable for demanding applications. It is an ideal choice for embedded applications requiring intensive processing capabilities, such as automotive, industrial control, medical equipment, and IoT devices.

Key Features:

• Core: ARM Cortex-M4 with FPU operating at frequencies up to 168 MHz.
• Memory: 1 Mbyte of Flash memory and 192+4 Kbytes of SRAM.
• Performance: A benchmark score of 210 DMIPS/1.25 DMIPS/MHz (Dhrystone 2.1), and an Adaptive real-time accelerator (ART Accelerator™) which allows zero-wait-state execution from Flash memory.
• Connectivity: Three 12-bit ADCs, two DACs, a low-power RTC, twelve general-purpose 16-bit timers including two PWM timers for motor control, and two general-purpose 32-bit timers.
• Rich Peripherals: Up to 17 communication interfaces, including six SPIs, three I2Cs, two I2Ss, three USARTs, two UARTs, CAN, and USB OTG HS/FS.
• Operating Voltage: Ranges from 1.8 to 3.6 volts, ensuring flexibility for various power supply designs.
• Package: LQFP100 package, which is conducive for space-constrained applications.

Advanced Capabilities:

The STM32F407VGT6 MCU also features advanced capabilities such as real-time acceleration, memory protection unit (MPU), and a flexible static memory controller supporting Compact Flash, SRAM, PSRAM, NOR, and NAND memories. It includes a comprehensive set of power-saving modes, allowing the design of low-power applications.

Development Support:

STMicroelectronics provides robust development support for the STM32F407VGT6 with a wide range of software tools, including the STM32Cube software development kit which comprises a Hardware Abstraction Layer (HAL), middleware components, and examples. Additionally, the extensive STM32 ecosystem encompasses development boards, software IDEs, and configuration tools to expedite development processes.

Overall, the STM32F407VGT6 microcontroller is a versatile and powerful component that brings efficiency and performance to a new level, addressing the needs of complex and sophisticated applications.
