The STM32F101ZDT6 is a high-performance ARM Cortex-M3 based microcontroller from STMicroelectronics, tailored for a wide range of applications. This advanced microcontroller is part of the STM32F1 series, which is renowned for its balanced combination of power efficiency, processing capabilities, and integration.
Key Features
- Core: ARM Cortex-M3 32-bit RISC core operating at a frequency of up to 36 MHz.
- Memory: Equipped with 384 KB of flash memory and 64 KB of SRAM, providing ample space for complex applications.
- I/O Ports: Offers up to 51 GPIOs with various digital, analog, and alternate function capabilities.
- Communication Interfaces: Includes multiple communication interfaces such as I2C, SPI, USART, USB, and CAN, enabling versatile connectivity options.
- ADC: Features a 12-bit, 1 μs Analog-to-Digital Converter (ADC) with up to 16 channels, allowing precise measurement of analog signals.
- Timers: Comprehensive set of timers, including a PWM timer for motor control, and general-purpose timers for a wide range of timing operations.
- Debugging: Integrated debugging and programming features through Serial Wire Debug (SWD) and JTAG interfaces.
- Power Efficiency: Supports multiple power-saving modes, including Sleep, Stop, and Standby, to optimize power consumption.
- Supply Voltage: Operates in a wide range of supply voltages from 2.0 to 3.6 V, suitable for battery-powered and low-power applications.
- Package: Available in an LQFP144 package, providing a compact footprint for space-constrained applications.
- Temperature Range: Specified for operation from -40°C to +85°C, ensuring reliable performance across diverse environmental conditions.
Applications
The STM32F101ZDT6 is ideal for a variety of applications, including industrial control systems, motor drives, medical equipment, consumer electronics, and IoT devices. Its robust feature set and flexible peripherals make it a go-to choice for designers seeking a microcontroller that delivers both performance and versatility.
