Products specifications Report Issue?

Categories Circuit Protection
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 1
STAND-OFF Voltage (Vwm) 30.8V
Minimum Breakdown Voltage 34.2V
Max Clamping Voltage 64.3V
Peak Pulse Current(Ippm) 156A (8/20μs)
Power Dissipation - Pd 1500W (1.5kW)
Applications General Purpose
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SMC
Win Source Part Number 1096936-SM15T36CA
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian SM15T36CA CAD Model

Description

SM15T36CA from STMicroelectronics is a TVS diode designed for transient voltage protection in electronic circuits that may be exposed to surge events, ESD, or other fast overvoltage conditions. Devices in this category are commonly used to help protect power lines, industrial interfaces, telecom equipment, automotive-related electronics, and embedded control boards where robust suppression behavior is important for system reliability. Engineers often select TVS diodes like SM15T36CA to reduce the risk of damage to downstream components and improve field durability in harsh electrical environments. As a protection component from a major semiconductor manufacturer, it is positioned as a practical choice for designs that need established surge protection from a recognized supplier. The current lifecycle status for this part is information not available, so design and sourcing teams should verify availability directly with STMicroelectronics or authorized distributors. RoHS compliance information is also not available in the provided data and should be confirmed using official manufacturer documentation before procurement or release.
