STMicroelectronics M95M02-DRCS6TP/K EEPROM

The M95M02-DRCS6TP/K is a 2 Mbit serial EEPROM memory module from STMicroelectronics, designed to provide robust, high-capacity data storage for a wide array of electronic applications. This device utilizes the standard Serial Peripheral Interface (SPI) to ensure compatibility with a broad range of microcontrollers and is well-suited for applications requiring frequent and reliable data storage and retrieval.

Key Features

• Memory Capacity: The module offers a substantial storage space of 2 Mbit, allowing for the storage of various configurations, user settings, or any other data-intensive information.
• Data Retention: It boasts an impressive data retention period of over 40 years, ensuring the longevity and durability of the stored information.
• Write Endurance: With a high write endurance of 1 million write cycles per byte, this EEPROM can handle a significant amount of data writing operations without degradation.
• High-Speed SPI Interface: The device supports a fast SPI clock frequency of up to 10 MHz, enabling quick data transfer rates that are essential for performance-critical applications.
• Operating Voltage Range: The M95M02-DRCS6TP/K operates across a voltage range of 1.8V to 5.5V, providing flexibility in different power environments and compatibility with both low-power and standard logic level systems.

Applications

The EEPROM module is versatile and can be used in a variety of applications, including:

• Industrial automation and process control systems
• Consumer electronics, such as set-top boxes and gaming consoles
• Automotive applications, including car radios and navigation systems
• Medical devices that require reliable and non-volatile data storage
• Telecommunication systems, including modems and routers

The M95M02-DRCS6TP/K is available in an 8-pin package, making it compact and easy to integrate into existing designs. The device also features software write protection for the entire memory array, further securing the integrity of the data. With its combination of high capacity, speed, and reliability, the M95M02-DRCS6TP/K from STMicroelectronics is an excellent choice for designers seeking a non-volatile memory solution that can stand the test of time.
