Product Overview: M74HC4094B1R

The M74HC4094B1R is a high-performance integrated circuit designed and manufactured by STMicroelectronics, a global leader in semiconductor solutions. This device is part of the HC family and is a 8-stage shift-and-store bus register that utilizes advanced silicon-gate CMOS technology to achieve operating speeds similar to LSTTL, with the low power consumption of standard CMOS integrated circuits.

Key Features

• High-Speed Operation: The M74HC4094B1R is capable of high-speed operation, making it suitable for a variety of applications that require quick data processing and transfer.
• Low Power Consumption: Thanks to the CMOS technology, the device has a very low power consumption, which is ideal for battery-powered devices and energy-saving applications.
• 8-Bit Serial-In/Parallel-Out Shift Register: The shift register allows serial input to be converted into parallel output, enabling efficient data handling and storage.
• 3-State Outputs: The device features 3-state outputs, providing the option for direct driving of data buses.
• Additional Output from Last Stage: An extra output from the last stage allows for serial expansion, making the device versatile for various serial data processing tasks.

Applications

The M74HC4094B1R is suited for a wide range of applications, including:

• Serial-to-parallel data conversion
• Data storage and transfer
• Automotive systems
• Communication systems
• Instrumentation and control systems
• Processors and microcontroller extensions

Technical Specifications

• Supply Voltage Range: 2.0 to 6.0 V
• Operating Temperature Range: -55°C to 125°C
• Package: The device is available in a DIP16 (dual in-line package) for easy integration into various circuit designs.

The M74HC4094B1R from STMicroelectronics is a reliable and versatile component that provides a balance between performance and power efficiency, making it an excellent choice for designers seeking to optimize their digital systems.
