The L6206D013TR from STMicroelectronics is a high-performance dual full-bridge driver designed to drive bipolar stepper motors or bidirectional control of two DC motors. This integrated circuit is part of STMicroelectronics' extensive range of motor drivers, known for their reliability and efficiency in various applications.

Key Features

• Operating Voltage: The device operates at a supply voltage range from 8 V to 52 V, making it versatile for a variety of power requirements.
• Output Current: It can deliver up to 1 A per channel with peak current up to 1.2 A, offering robust performance for a wide range of motor types.
• Cross-Conduction Protection: With integrated cross-conduction protection, the L6206D013TR ensures that there is no simultaneous conduction of the transistors, preventing device damage.
• Thermal Shutdown: An internal thermal shutdown feature protects the device from overheating, enhancing the safety and longevity of the motor driver.
• Under-Voltage Lockout: The under-voltage lockout function ensures that the driver operates at safe voltage levels to prevent malfunctions.
• Non-Dissipative Overcurrent Protection: This innovative feature uses the back-EMF voltage monitoring to protect the device against overcurrent conditions without the need for external sense resistors.

Applications

The L6206D013TR is suitable for a variety of applications that require precise and efficient motor control. It is commonly used in:

• Office Automation Machines
• Factory Automation and Robotics
• Vending Machines
• Point of Sale Terminals
• 3D Printers
• Surveillance Systems

Package and Quality

The L6206D013TR is available in a 36-pin PowerSO package, which is designed for optimal heat dissipation and space-saving on PCBs. The device is manufactured under STMicroelectronics' commitment to quality and reliability, ensuring that it meets the requirements of the most demanding motor control applications.

With its advanced features and robust design, the L6206D013TR motor driver is an excellent choice for designers looking to improve the performance and efficiency of their motor control systems.
