M05 Meder Electronic
Same model may have multiple batches, images only for reference.

M05

Part No M05
Manufacturer Standex-Meder Electronics
Catalog Misc Products
Description MAGNET 0.910"L X 0.55"W PBT
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Magnets - Sensor Matched Magnets
Mfr Standex-Meder Electronics
Series M05
Package Bulk
Product Status Active
For Use With/Related Products MK05
Housing Material Polybutylene Terephthalate (PBT), Glass Filled
Material - Magnet Alnico 5 (AlNiCo)
Package / Case Flange Mount
Size 0.910" L x 0.550" W x 0.230" H (23.0mm x 13.9mm x 5.90mm)
Temperature Range - Operating 70°C (TA)
Standard Package 120 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8505.11.0010
Win Source Part Number 627217-M05
Ultra Librarian 3D Model Ultra Librarian M05 CAD Model

Description

The M05 series of matched magnets is designed for use with MK05 sensors and transducers and is manufactured by Standex-Meder Electronics.

  • Material: Alnico 5 (AlNiCo)
  • Housing Material: Polybutylene Terephthalate (PBT) with glass filling
  • Package: Flange Mount
  • Size: 0.910" L x 0.550" W x 0.230" H (23.0mm x 13.9mm x 5.90mm)
  • Standard Package: 120 pieces
  • Operating Temperature: 70°C (TA)
  • Status: Active
