Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Thyristors - SCRs
Mfr Solid State Inc.
Package Bulk
Product Status Active
Voltage - Off State 200 V
Voltage - Gate Trigger (Vgt) (Max) 1 V
Current - Gate Trigger (Igt) (Max) 1 mA
Voltage - On State (Vtm) (Max) 1.75 V
Current - On State (It (RMS)) (Max) 1.6 A
Current - Hold (Ih) (Max) 5 mA
Current - Off State (Max) 500 µA
Current - Non Rep. Surge 50, 60Hz (Itsm) 15A
SCR Type Standard Recovery
Temperature Range - Operating -65°C ~ 110°C (TJ)
Mounting Type Through Hole
Package / Case TO-205AD, TO-39-3 Metal Can
Supplier Device Package TO-39
Standard Package 10 pcs
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 638587-MCR1906-4
Ultra Librarian 3D Model Ultra Librarian MCR1906-4 CAD Model

Description

The 638587-MCR1906-4 is a thyristor component designed for use in discrete semiconductor products.

  • Category: SCR (Silicon Controlled Rectifier)
  • Recovery Type: Standard
  • Voltage Off State: 200 V
  • Gate Trigger Voltage (Vgt): 1 V
  • Maximum Gate Trigger Current (Igt): 1 mA
  • Maximum On-State Voltage (Vtm): 1.75 V
  • Maximum RMS On-State Current (It (RMS)): 1.6 A
  • Maximum Off-State Current: 500 µA
  • Non-Repetitive Surge Current: 15A @ 50 or 60Hz
  • Package Type: TO-205AD, TO-39-3 Metal Can
  • Mounting: Through hole
  • Operating Temperature Range: -65°C to 110°C (TJ)
  • Product Status: Active
  • Manufacturer: Solid State Inc.
