ES3E MIC GROUP RECTIFIERS
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr SMC Diode Solutions
Package Tape & Reel
Product Status Obsolete
Technology Standard
Voltage - DC Reverse (Vr) (Max) 300 V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 1.25 V @ 3 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 35 ns
Current - Reverse Leakage @ Vr 5 µA @ 300 V
Capacitance @ Vr, F 45pF @ 4V, 1MHz
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Supplier Device Package SMC (DO-214AB)
Operating Temperature - Junction -55°C ~ 150°C
Base Product Number ES3
Standard Package 3,000 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 589800-ES3E
Ultra Librarian 3D Model Ultra Librarian ES3E CAD Model

Description

The 589800-ES3E is a fast recovery diode used for rectification purposes.

  • Maximum Reverse Voltage (Vr): 300V
  • Average Rectified Current (Io): 3A
  • Forward Voltage (Vf): 1.25V @ 3A
  • Reverse Recovery Time (trr): 35ns
  • Reverse Leakage Current: 5µA @ 300V
  • Capacitance: 45pF @ 4V and 1MHz
  • Operating Temperature Range: -55°C to 150°C
  • Mounting Type: Surface Mount
  • Package: DO-214AB
  • Manufacturer: SMC Diode Solutions
  • Series: ES3
  • Product Status: Obsolete
  • REACH: Unaffected
  • ECCN: EAR99
