DB157 Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr SMC Diode Solutions
Package Tube
Product Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 1 kV
Current - Average Rectified (Io) 1.5 A
Voltage - Forward (Vf) (Max) @ If 1.1 V @ 1.5 A
Current - Reverse Leakage @ Vr 5 µA @ 1000 V
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Package / Case 4-EDIP (0.321", 8.15mm)
Supplier Device Package DB-M
Base Product Number DB157
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 584110-DB157
Ultra Librarian 3D Model Ultra Librarian DB157 CAD Model

Description

The 584110-DB157 is a single phase bridge rectifier diode designed for rectification applications. It has a maximum forward voltage of 1.1 V at a current of 1.5 A and a maximum reverse leakage current of 5 μA at a reverse voltage of 1000 V.

  • Maximum Forward Voltage: 1.1 V @ 1.5 A
  • Maximum Reverse Leakage Current: 5 μA @ 1000 V
  • Current Rating: 1.5 A
  • Package Type: 4-EDIP (0.321", 8.15mm)
  • Mounting: Through-Hole
  • Operating Temperature Range: -55°C to 150°C
  • Standard Package: 50 pcs
  • Manufacturer: SMC Diode Solutions
  • Series: DB157
  • Market Status: Active
