ST-7-20

Name: ST-7-20
Brand: Signal Transformer
SKU: 1189505
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	ST-7-20
Manufacturer	Signal Transformer
Catalog	Power Transformers
Description	PWR XFMR LAMINATED 36VA TH /
Datasheet	ST-7-20 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Transformers>Power Transformers
Mfr	Signal Transformer
Series	ST
Package	Box
Type	Laminated Core
Voltage - Primary	115V
Voltage - Secondary (Full Load)	Parallel 10V, Series 20V
Current - Output (Max)	Parallel 3.6A, Series 1.8A
Primary Winding(s)	Single
Secondary Winding(s)	Dual
Center Tap	No
Power - Max	36VA
Mounting Type	Through Hole
Termination Style	PC Pin
Dimension	66.70mm L x 55.50mm W
Height - Seated (Max)	40.40mm
Voltage - Isolation	2500Vrms
Weight	1.1 lbs (499 g)
MSL Level	Not Applicable
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.31.4035
Other Names	595-1175
Standard Package	20
Win Source Part Number	1189505-ST-7-20
Ultra Librarian 3D Model	Ultra Librarian ST-7-20 CAD Model

Description

The Signal Transformer ST-7-20 is a laminated core power transformer with a maximum power of 36VA.

Voltage Isolation: 2500Vrms
Primary Voltage: 115V
Termination Style: PC Pin
Mounting: Through Hole
Parallel Output Current: 3.6A
Series Output Current: 1.8A
Parallel Output Voltage: 10V
Series Output Voltage: 20V
Height: 40.40mm
Weight: 1.1 lbs (499 g)
Package: Box
Series: ST
