The 79L24 is a three-terminal negative voltage regulator, part of the 79Lxx series. These regulators are widely used to provide a stable negative voltage output for various electronic circuits. The 79L24 specifically delivers a fixed output voltage of -24V.

Applications

• Power Supplies: Functions as a negative voltage regulator in power supply designs.
• Instrumentation: Used in test and measurement equipment requiring precise negative voltage references.
• Linear Regulation: Used for linear voltage regulation applications where a stable -24V is needed.
• Analog Circuits: Provides a clean negative power supply for operational amplifiers and other analog components.

Features

• Fixed Output Voltage: Provides a stable -24V output.
• Low Quiescent Current: Minimizes wasted power, enhancing energy efficiency.
• Short-Circuit Protection: Protects the regulator and connected circuitry from damage due to output shorts.
• Thermal Overload Protection: Automatically shuts down the regulator to prevent damage from overheating.
• Compact Package: Available in small packages like TO-92 and SOIC, suitable for space-constrained applications.

Benefits

• Stable Negative Voltage: Ensures a reliable -24V supply for sensitive electronic components.
• Simplified Design: Requires minimal external components, reducing design complexity and cost.
• Enhanced Reliability: Built-in protection features ensure safe and reliable operation.
• Cost-Effective: Provides a low-cost solution for negative voltage regulation needs.

Additional Details

External capacitors are typically required at the input and output to ensure stability and optimal performance. The input capacitor helps to filter out noise and voltage variations from the input supply, while the output capacitor helps to maintain a stable output voltage during load changes. The input voltage must be a few volts more negative than the desired output voltage for proper regulation. Consult the manufacturer's datasheet for specific application notes, recommended component values, and thermal considerations.
