STW8Q14D Seoul Semiconductor
Same model may have multiple batches, images only for reference.

STW8Q14D

Part No STW8Q14D
Manufacturer Seoul Semiconductor Inc.
Catalog LED Lighting - White
Description LED WHITE SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Optoelectronics - White LED Lighting
Mfr Seoul Semiconductor Inc.
Series 5630
Package Tape & Reel
Product Status Active
Color White
Current - Test 65mA
Voltage - Forward (Vf) (Typ) 2.8V
CRI (Color Rendering Index) 80
Current - Max 200mA
Viewing Angle 120°
Mounting Type Surface Mount
Package / Case 4-SMD, Flat Lead Exposed Pad
Supplier Device Package 5630
Size / Dimension 0.205" L x 0.118" W (5.20mm x 3.00mm)
Height - Seated (Max) 0.033" (0.85mm)
Thermal Resistance of Package 10°C/W
Base Product Number STW8Q14
Standard Package 1,000 pcs
ECCN EAR99
HTSUS 8541.41.0000
Win Source Part Number 679720-STW8Q14D
Ultra Librarian 3D Model Ultra Librarian STW8Q14D CAD Model

Description

The 679720-STW8Q14D is a white LED lighting component manufactured by Seoul Semiconductor Inc.

  • Size: 0.205" L x 0.118" W (5.20mm x 3.00mm)
  • Seated Height: 0.033" (0.85mm)
  • Maximum Current: 200mA
  • Viewing Angle: 120 degrees
  • Forward Voltage (Vf): Typically 2.8V
  • Current for Testing: 65mA
  • Color Rendering Index (CRI): 80
  • Thermal Resistance of the Package: 10 degrees Celsius per watt
