The SC4509WLTRT is a wide input voltage, high efficiency, synchronous step-down (Buck) regulator from Semtech. It is designed to operate from input voltages ranging from 3V to 36V and provides a precisely regulated output voltage. The device features a low RDS(ON) internal MOSFETs, which contribute to high efficiency and minimize power dissipation. It is ideal for various industrial, automotive, and portable applications. The SC4509 also incorporates protection features such as over-current protection and over-temperature protection.

Applications

• Industrial Power Supplies: Used in robust and reliable power supplies for industrial equipment.
• Automotive Systems: Powers various electronic components in vehicles, tolerating wide input voltage fluctuations.
• Battery-Powered Devices: Efficiently regulates voltage in portable devices powered by batteries.
• Distributed Power Architectures: Provides point-of-load regulation in distributed power systems.
• Networking Equipment: Powers network switches, routers, and other networking devices.

Features

• Wide Input Voltage Range: Operates from 3V to 36V input voltage.
• High Efficiency: Achieves up to 95% efficiency, minimizing power loss.
• Integrated MOSFETs: Internal low RDS(ON) MOSFETs for high efficiency.
• Adjustable Output Voltage: Output voltage can be adjusted using external resistors.
• Fixed Switching Frequency: Operates at a fixed frequency for predictable performance.
• Over-Current Protection: Protects the device and load from excessive current.
• Over-Temperature Protection: Protects the device from thermal damage.
• Small Package: Available in a compact package for space-constrained applications.

Benefits

• Versatile Input Voltage: Accommodates a wide range of input voltage sources.
• Energy Efficiency: Reduces power consumption and heat generation.
• Simplified Design: Integrated MOSFETs reduce component count and simplify design.
• Flexibility: Adjustable output voltage allows for customization.
• Reliability: Built-in protection features ensure reliable operation.
• Compact Size: Suitable for space-sensitive applications.

Additional Details

The SC4509WLTRT's high efficiency is achieved through synchronous rectification and low RDS(ON) MOSFETs. This reduces power loss and minimizes heat generation. The adjustable output voltage allows designers to tailor the output voltage to their specific needs by using external resistors. The fixed switching frequency simplifies design and ensures predictable performance. The device also incorporates over-current protection (OCP) to safeguard the regulator and the load against short circuits or excessive current draw. Over-temperature protection (OTP) prevents the device from being damaged by excessive heat. The SC4509WLTRT is typically packaged in a thermally enhanced package for efficient heat dissipation. It's commonly used in applications where high efficiency, wide input voltage range, and small size are critical requirements.
