3402.0016.22 Real Image
Same model may have multiple batches, images only for reference.

3402.0016.22

Part No 3402.0016.22
Manufacturer Schurter Inc.
Catalog Fuses
Description Surface Mount Fuse, 7.4 x 3.1 mm, Quick-Acting F, 63 VAC, 63 VDC | FUSE BOARD MNT 4A 63VAC/VDC 2SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Schurter Inc.
Packaging Reel
Fuse Type Board Mount (Cartridge Style Excluded)
Current Rating (Amps) 4A
Voltage Rating - AC 63V
Voltage Rating - DC 63V
Response Time Fast Blow
Manufacturer Package 2-SMD, J-Lead
Mounting Style SMD
Breaking Capacity at Rated Voltage 50A
Melting I2t 2.1
Approvals cURus
Temperature Range - Operating -55°C ~ 125°C
Parts Dimension 0.291" L x 0.122" W x 0.102" H (7.40mm x 3.10mm x 2.60mm)
Manufacturer Pack Quantity 1
MSL Level Vendor Undefined
Win Source Part Number 1128246-3402.0016.22
Manufacturer Homepage www.schurterinc.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 3402.0016.22 CAD Model

Description

The Schurter Inc. board mount fuse is perfect for use in circuit protection. It has a voltage rating of AC 63V and DC 63V, and a fast blow response time. The board mount fuse is from Schurter Inc.

  • Voltage Rating: AC 63V and DC 63V
  • Response Time: Fast Blow
  • Current Rating: 4A
  • Breaking Capacity @ Rated Voltage: 50A
  • Package: Reel
  • Mounting: SMD
  • Operating Temperature Range: -55°C ~ 125°C
  • Dimensions: 0.291" L x 0.122" W x 0.102" H (7.40mm x 3.10mm x 2.60mm)
  • Application: Circuit Protection
