2070.0018.24 Schurter Inc.
Same model may have multiple batches, images only for reference.

2070.0018.24

Part No 2070.0018.24
Manufacturer Schurter Inc.
Catalog Fuses
Description Surface Mount Fuse, 11 x 4.6 mm, Quick-Acting F, Telecom | FUSE BRD MNT 1.6A 250VAC/VDC SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Schurter Inc.
Packaging Tape and Reel
Status Obsolete
Fuse Type Board Mount (Cartridge Style Excluded)
Current Rating (Amps) 1.6A
Voltage Rating - AC 250V
Voltage Rating - DC 250V
Response Time Fast Blow
Manufacturer Package 2-SMD, J-Lead
Mounting Style SMD
Breaking Capacity at Rated Voltage 100A
Melting I2t 0.84
Approvals cURus, VDE
Temperature Range - Operating -40°C ~ 125°C
Parts Dimension 0.433" L x 0.181" W x 0.154" H (11.00mm x 4.60mm x 3.90mm)
Manufacturer Pack Quantity 2,000
MSL Level Vendor Undefined
Win Source Part Number 1122891-2070.0018.24
Manufacturer Homepage www.schurterinc.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 2070.0018.24 CAD Model

Description

The Schurter Inc. 2070.0018.24 is an obsolete electronic component that was used in various devices. The manufacturer homepage is www.schurterinc.com and the Win Source Part Number is 1122891-2070.0018.24.

  • Response Time: fast blow
  • Mounting: SMD
  • Approvals: cURus and VDE
  • Voltage Rating: 250V AC and 250V DC
  • Manufacturer Package: 2-SMD, J-Lead
  • Manufacturer Pack Quantity: 2,000
  • MSL Level: vendor undefined
  • Parts Dimension: 0.433" L x 0.181" W x 0.154" H (11.00mm x 4.60mm x 3.90mm)
  • Current Rating: 1.6A
  • Breaking Capacity @ Rated Voltage: 100A
