The TMG20C60F is a high-power thyristor module manufactured by SanRex Corporation. This module is designed for high-voltage, high-current applications and is commonly used in industrial power control systems, motor drives, and various types of power conversion equipment. The TMG20C60F offers robust performance and reliability in demanding environments.

Applications:

• Industrial Motor Drives
• Power Conversion Systems
• Soft Starters
• High-Voltage Power Supplies
• Welding Equipment

Features:

• High Voltage Capability: Up to 600V
• High Current Capability: 20A
• Isolated Baseplate
• High Surge Current Capability
• Compact Module Design

Benefits:

• Reliable operation in high-voltage and high-current applications.
• Easy integration into power control systems due to its modular design.
• Improved system safety with an isolated baseplate.
• Enhanced system durability due to high surge current capability.
• Reduced space requirements due to compact module size.

Technical Specifications:

The TMG20C60F has a maximum repetitive peak reverse voltage (VRRM) of 600V and a maximum average on-state current (IT(AV)) of 20A. It features an isolated baseplate for enhanced safety and thermal management. The module is designed to withstand high surge currents, making it suitable for applications with transient voltage spikes. The operating junction temperature range is typically between -40°C and +125°C. The gate trigger current (IGT) and gate trigger voltage (VGT) are specified to ensure proper triggering of the thyristor. The thermal resistance between the junction and the case is low, facilitating efficient heat dissipation. The module is typically mounted on a heatsink to maintain optimal operating temperatures.
