The TSW-150-14-L-D is a 100-position rectangular connector with a pitch of 0.100" (2.54mm) from Samtec Inc..

• Positions: 100
• Pitch: 0.100" (2.54mm)
• Connector Type: Header
• Contact Gender: Male Pin
• Loaded Positions: All
• Rows: Two
• Termination: Solder
• Contact Material: Phosphor Bronze
• Contact Finish (Mating): Gold
• Contact Finish (Post): Tin
• Insulation Material: Polybutylene Terephthalate (PBT)
• Insulation Color: Black
• Insulation Height: 0.100" (2.54mm)
• Mounting Type: Through Hole
• Temperature Range: -55°C to 125°C
• Flammability Rating: UL94 V-0
• Application: Board to Board or Cable
