Part No TSM10301SSVPTR
Manufacturer Samtec Inc.
Catalog Rectangular Connectors
Description CONN HEADER 3POS .100" SMD
Datasheet
TSM10301SSVPTR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer Samtec Inc.
Packaging Reel - TR
Status Active
Connector Type Header
Contact Type Male Pin
Pitch - Mating 2.54mm
Style Board to Board or Cable
Shrouding Unshrouded
Number of Positions 3
Number of Positions Loaded All
Number of Rows 1
Mounting SMD (SMT)
Termination Solder
Contact Length - Mating 0.230" (5.84mm)
Insulation Height 0.100" (2.54mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 30μin (0.76μm)
Contact Finish - Post Tin
Insulation Material Liquid Crystal Polymer (LCP)
Features Pick and Place
Temperature Range - Operating -55°C to 125°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Win Source Part Number 048333-TSM10301SSVPTR
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TSM10301SSVPTR CAD Model

Description

The TSM10301SSVPTR header connector by Samtec Inc. is a male pin connector with 3 positions.

  • Manufacturer: Samtec Inc.
  • Connector Type: Header
  • Positions: 3
  • Gender: Male Pin
  • Feature: Pick and Place, Loaded
  • Shrouding: Unshrouded
  • Contact Shape: Square
  • Insulation Material: Liquid Crystal Polymer (LCP)
  • Flammability Rating: UL94 V-0
  • Contact Finish: Gold (mating), Tin (post)
  • Contact Finish Thickness: 30μin (0.76μm) (mating)
  • Pitch (mating): 2.54mm
  • Operating Temperature Range: -55°C to 125°C
