The SFMC-137-03-L-D is a rectangular connector manufactured by Samtec Inc.

• Series: Tiger Eye™ SFMC series.
• Positions: 74 positions.
• Connector Type: receptacle type connector.
• Contact Type: female sockets.
• Positions Loaded: All positions are loaded.
• Rows: two rows.
• Termination: solder.
• Fastening Type: push-pull.
• Contact Material: beryllium copper.
• Contact Finish: gold.
• Voltage Rating: not provided.
• Mated Stacking Heights: not provided.
• Insulation Material: liquid crystal polymer (LCP).
• Insulation Color: black.
• Mounting Type: through hole.
• Pitch - Mating: 0.050" (1.27mm).
• Contact Finish Thickness - Mating: 10.0µin (0.25µm).
• Contact Finish - Post: tin.
• Temperature Range - Operating: -55°C to 125°C.
• ECCN: EAR99.
