The SFSD-30-28-G-16.00-DR-NDX is a double-row, 30-position (2x15) socket strip from Samtec's SFSD series. It features a 0.050" (1.27 mm) pitch, gold-plated contacts ('G'), and a through-hole termination style. '16.00' refers to the stack height in millimeters, measured from the board surface to the top of the connector. 'DR' indicates a double-row configuration, and 'NDX' typically indicates a customer-specific modification or a non-standard option, often related to packaging or manufacturing processes.

Applications

• High-density board-to-board connections.
• Signal routing in compact electronic devices.
• Industrial control systems.
• Medical equipment.
• Telecommunications applications.

Features

• 0.050" (1.27 mm) pitch for high-density packaging.
• 30 positions in a double-row configuration (2x15).
• Gold-plated contacts for superior conductivity and corrosion resistance.
• Through-hole termination for a robust mechanical connection.

Benefits

• Enables compact and space-saving designs.
• Provides reliable signal transmission with gold-plated contacts.
• Ensures long-term performance and reliability in harsh environments.
• Offers a secure and stable connection to the PCB.

Additional Details

The SFSD series is designed for applications requiring reliable and high-density interconnects. The gold plating ensures low contact resistance and excellent resistance to corrosion, making it suitable for demanding environments. The 'NDX' designator typically indicates a specific customer requirement or an internal Samtec specification related to packaging or specialized manufacturing. Mating connectors are usually terminal strips from the same SFSD series or a compatible series with the same pitch and number of positions.
