The SDL-129-G-11 is a terminal strip manufactured by Samtec Inc., specifically designed for creating robust and space-efficient board-to-board connections. As part of the SDL series, it offers a reliable solution for various electronic applications that demand compact designs and consistent connectivity.

Applications

• High-Density Circuit Boards: Often used in densely populated PCBs where space is limited.
• Medical Devices: Integrated into portable medical equipment and diagnostic tools requiring compact connections.
• Consumer Electronics: Found in smartphones, tablets, and other consumer devices where space is a premium.
• Industrial Automation: Employed in compact PLCs, sensor modules, and other industrial control equipment.
• Internet of Things (IoT) Devices: Used in IoT gateways, smart sensors, and other connected devices.

Features

• Number of Rows: Single row configuration for maximum space efficiency.
• Number of Positions: 29 positions, allowing for a large number of connections within a small area.
• Pitch: Standard 0.100" (2.54mm) pitch, ensuring compatibility with standard PCBs and components.
• Termination Style: Through-hole termination providing a secure and reliable connection to the PCB.
• Insulator Material: High-temperature thermoplastic, which provides excellent electrical insulation and withstands soldering heat.
• Contact Material: Typically made from phosphor bronze or beryllium copper, known for their conductivity and durability.
• Contact Plating: Gold or tin plating on the contact area ensuring reliable electrical contact and corrosion resistance.
• Profile: Low-profile design to minimize vertical space requirements in compact devices.

Benefits

• Space-Saving: The low-profile design and compact footprint make it ideal for use in miniaturized electronic devices.
• Reliable Connection: Provides a stable and consistent electrical connection minimizing signal loss and ensuring reliable performance.
• Durable: Constructed from high-quality materials to ensure long-term reliability and resistance to environmental factors.
• Easy Installation: Through-hole termination simplifies the soldering process and allows for easy integration into PCB designs.
• Versatile: Suitable for a wide range of applications where space is limited and reliable connections are required.

Additional Details

The SDL-129-G-11 terminal strip is engineered for ease of use and dependable performance in tight spaces. Its through-hole termination method ensures a robust mechanical connection to the PCB. The high-temperature thermoplastic insulator is designed to withstand reflow soldering processes without deformation. The gold or tin-plated contacts ensure consistent electrical performance, even in challenging environmental conditions. This terminal strip is an excellent choice for applications requiring a dependable and compact board-to-board connection solution.
