IPD1-02-D-K Real Image
Same model may have multiple batches, images only for reference.

IPD1-02-D-K

Part No IPD1-02-D-K
Manufacturer Samtec Inc.
Catalog Circular Connectors - Housings
Description CONN RECEPT .100" 4POS / 4 Rectangular Connectors - Housings Receptacle White 0.100" (2.54mm)
Datasheet
IPD1-02-D-K Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Housings
Mfr Samtec Inc.
Series Mini Mate® IPD1
Package Bulk
Connector Type Receptacle
Contact Type Female Socket
Number of Positions 4
Pitch 0.100" (2.54mm)
Number of Rows 2
Row Spacing 0.100" (2.54mm)
Mounting Type Free Hanging (In-Line)
Contact Termination Crimp
Fastening Type Latch Lock
Color White
Features Polarizing Key
Note Contacts Not Included
Base Product Number IPD1-02
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8538.90.6000
Other Names SAM8818,IPD1-02-D-K-ND
Standard Package 1
Win Source Part Number 1164680-IPD1-02-D-K
Ultra Librarian 3D Model Ultra Librarian IPD1-02-D-K CAD Model

Description

The IPD1-02-D-K is a rectangular connector housing in the Mini Mate® IPD1 series manufactured by Samtec Inc.

  • Category: Connector
  • Win Source Part Number: 1164680-IPD1-02-D-K
  • Series: Mini Mate® IPD1
  • Number of Positions: N/A
  • Pitch: N/A
  • Color: N/A
  • Features: Polarizing Key
  • Connector Type: Receptacle
  • Contact Type: Female Socket
  • Number of Rows: N/A
  • Row Spacing: N/A
  • Fastening Type: N/A
  • Package: N/A
  • Contact Termination: N/A
  • Note: N/A
  • Standard Package: N/A
  • Mounting Type: N/A
  • Alternative Parts (Cross-Reference): N/A
