The BBD series 54-position male pin header connector from Samtec Inc. is a board-to-board style connector designed for interconnecting PCBs.

• Pitch: 0.100" (2.54mm)
• Rows: Two
• Positions Loaded: All
• Fastening Type: Push-pull
• Termination: Solder
• Contact Finish for Mating: Gold with a thickness of 20.0µin (0.51µm)
• Contact Finish for Post: Nickel with a thickness of 50.0µin (1.27µm)
• Contact Length for Post and Mating: 0.125" (3.18mm)
• Overall Contact Length: 0.585" (14.86mm)
• Insulation Height: 0.335" (8.51mm)
• Operating Temperatures: -55°C to 125°C
• Package: Tube
• Standard Package: 8
• Insulation Material: Polyester, glass-filled
• Insulation Color: Black
