50YXH100MEFC8X11.5 Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Capacitors>Aluminum Electrolytic Capacitors
Manufacturer Rubycon
Packaging Bulk
Capacitance 100 µF
Tolerance ±20%
Voltage - Rated 50 V
Lifetime @ Temp. 7000 Hrs @ 105°C
Temperature Range - Operating -40°C ~ 105°C
Polarization Polar
Applications General Purpose
Ripple Current @ Low Frequency 277.5 mA @ 120 Hz
Ripple Current @ High Frequency 555 mA @ 100 kHz
Impedance 170 mOhms
Lead Spacing 0.138" (3.50mm)
Size / Dimension 0.315" Dia (8.00mm)
Height - Seated (Max) 0.512" (13.00mm)
Mounting Through Hole
Case / Package Radial, Can
RoHS Status ROHS3 Compliant
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Other Part Number 1189-2319,50YXH100MEFC8X11.5-ND
Standard Package 2,000
Win Source Part Number 1330509-50YXH100MEFC8X11.5
Ultra Librarian 3D Model Ultra Librarian 50YXH100MEFC8X11.5 CAD Model

Description

The Rubycon 1330509-50YXH100MEFC8X11.5 aluminum electrolytic capacitor is a general-purpose capacitor with a capacitance of 100 µF and a voltage rating of 50 V.

  • Application: General-Purpose
  • Capacitance: 100 µF
  • Voltage Rating: 50 V
  • Tolerance: ±20%
  • Lead Spacing: 0.138" (3.50mm)
  • Mounting Type: Through-Hole
  • Package: Radial Can
  • Lifetime: 7000 hours @ 105°C
  • Impedance: 170 mOhms
  • ESR: Not Specified
  • Ripple Current (Low Frequency): 277.5 mA @ 120 Hz
  • Ripple Current (High Frequency): 555 mA @ 100 kHz
  • Dimensions: 0.315" diameter and 0.512" height
  • Manufacturer: Rubycon
