Products specifications

Manufacturer Rohm Semiconductor
Win Source Part Number 1241970-RBQ30T65A
Manufacturer Homepage www.rohm.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian RBQ30T65A CAD Model

Description

The RBQ30T65A is a 650V, 30A Silicon Carbide (SiC) Schottky Barrier Diode (SBD) from Rohm Semiconductor. It's designed for power factor correction (PFC) circuits and secondary rectification in power supplies and inverters. SiC SBDs offer significant advantages over traditional silicon diodes, including lower forward voltage drop, faster reverse recovery time, and higher operating temperature.

Applications:

  • Power Factor Correction (PFC): Used in PFC circuits to improve power factor and reduce harmonic distortion.
  • Switch Mode Power Supplies (SMPS): Used as a secondary rectifier in SMPS to improve efficiency.
  • Inverters: Used in inverters for solar power, motor drives, and uninterruptible power supplies (UPS).
  • Electric Vehicle (EV) chargers: Used in EV chargers to improve efficiency and reduce size.
  • Welding machines: Used in welding machines to improve efficiency and reduce size.

Features:

  • 650V breakdown voltage: Suitable for high-voltage applications.
  • 30A forward current: Can handle high current loads.
  • Silicon Carbide (SiC) technology: Offers superior performance compared to silicon diodes.
  • Low forward voltage drop (VF): Minimizes power loss and improves efficiency.
  • Zero reverse recovery current (Irr): Eliminates reverse recovery losses and reduces EMI.

Benefits:

  • Improved power efficiency: Reduces energy consumption and lowers operating costs.
  • Reduced heat dissipation: Minimizes the need for heatsinks and improves system reliability.
  • Smaller system size: Enables the design of smaller and lighter power supplies and inverters.
  • Increased system reliability: The SiC SBD is more robust and reliable than traditional silicon diodes.
  • Faster switching speed: Enables higher switching frequencies, reducing the size of passive components.

Additional Details:

The RBQ30T65A is typically packaged in a TO-247 package. It's important to use appropriate heatsinking to manage the heat generated during operation at higher currents. The diode is lead-free and RoHS compliant. The operating junction temperature ranges from -55°C to +175°C. The forward voltage drop is typically 1.7V at 30A.
