Products specifications

Reference Date Code 16+Rohs
Reference case SOD723
Manufacturer Rohm Semiconductor
Manufacturer Homepage www.rohm.com
Win Source Part Number 743523-1SS400CM
Popularity Low
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 1SS400CM CAD Model

Description

The 1SS400CM is a small signal Schottky barrier diode manufactured by Rohm Semiconductor. This diode is designed for high-speed switching and rectification applications. It features low forward voltage drop and fast reverse recovery time, making it suitable for use in a wide range of electronic circuits.

Applications

  • High-speed switching circuits
  • Voltage clamping
  • Signal detection
  • DC-DC converters
  • Reverse polarity protection

Features

  • Low forward voltage drop
  • Fast reverse recovery time
  • Small signal diode
  • Surface mount package
  • High reliability

Benefits

  • Improves efficiency in switching applications
  • Minimizes power loss
  • Enables high-speed operation
  • Saves board space
  • Ensures long-term performance

Technical Specifications

  • Maximum Repetitive Peak Reverse Voltage (VRRM): 40 V
  • Average Forward Current (IF(AV)): 30 mA
  • Forward Voltage (VF): 0.45 V at IF = 10 mA
  • Reverse Current (IR): 100 nA at VR = 40 V
  • Total Capacitance (CT): 4 pF at VR = 0 V, f = 1 MHz
  • Operating Temperature Range: -40°C to +125°C
  • Package: SOT-23
